3 nyob rau hauv 1 Cholesterol Triglycerides HDL LDL CHOL / HDL Ratio Lipid Test Meter

Ntshav Lipid Analysis System yog npaj rau kev txiav txim kom muaj nuj nqis ntawm Total Cholesterol (TC), High Density Lipoprotein Cholesterol (HDL), Triglycerides (TG), thiab suav piv ntawm TC / HDL thiab Low Density Lipoprotein Cholesterol (LDL) hauv cov ntshav capillary. , venous tag nrho cov ntshav, plasma thiab serum.Cov Ntshav Lipid Analysis System muab cov txiaj ntsig. Lub 'meter' tuaj yeem ua haujlwm los ntawm kev them roj teeb.

Tsham tam sim no

Khoom Taw qhia

Khoom npe	Ntshav Lipid Analysis Meter
Qauv No.	LPM -102
Txoj kev	Reflectance Photometer
Cov khoom tsom xam	Tag nrho cov roj (cholesterol) siab, siab ceev lipoprotein, triglyceride
Kev ntsuas Range	TL: 2 59-12.93mmol/L (100-500mg/dL, 1mmol/L=38}.66mg/dL) HDL: 0 39-2.59mmol/L (15-100mg/dL, 1mmol/L=38.66mg/dL) TG: 0 51-7.34 mmol/L (45-650mg/dL, 1mmol/L=88.6mg/dL)
Chav ntsuas	mmol/L, mg/dL
Cov qauv	Tag nrho cov ntshav (peripheral thiab venous tib neeg cov ntshav), plasma thiab ntshav
Specimen Volume	Kev Xeem Ib Leeg: 10μL, 3-hauv-1 Kev Xeem: 35μL
Lub Sijhawm Xeem	TC, HDL, TG: hauv 120 vib nas this
Hwj chim Source	3 * AAA roj teeb
Roj teeb lub neej	Tom qab lub voj voog them 300 zaug, hluav taws xob kom txo tau 30 feem pua
Nco	800 Cov ntaub ntawv
Tsis siv neeg kaw	5 feeb tom qab siv kawg
Meter Loj	136MM * 66MM * 19MM
Meter Net Nyhav	90G
Meter Storage Conditions	0-55 degree ; Tsawg dua lossis sib npaug li 90 feem pua RH
Cov Txheej Txheem Kev Ua Haujlwm	10-40 degree ; Tsawg dua lossis sib npaug li 90 feem pua RH; Seal-Level Tsawg dua lossis sib npaug li 2000M

Txoj cai ntawm kev ntsuas

Lub ntsuas ntsuas siv lub hauv paus ntsiab lus ntawm photochemistry thiab siv nrog cov ntshav lipidxeem strips (LPS-101, TCS-101, TGS-101, HLS-101) .Tag nrho cov ntshav coj los uakuaj yog ntxiv rau hauv cov qauv cheeb tsam ntawm lub sawb. Nyob rau hauv tus txheej txheem ntawm ceev infiltration,cov ntshav lim tawm los yog yaj. Lub substrate reacts nrog enzymes thiabtshuaj nyob rau hauv cov tshuaj tiv thaiv txheej thiab ua rau cov xim hloov, ces cov xim sivyog proportional rau qhov concentration ntawm cov khoom.

Lub analyzer kuaj cov xim siv ntawm cov tshuaj tiv thaiv qhov kawg taw tes ntawm lub wavelength ntawm620nm, cov tshuaj concentration yog xam los ntawm lub reflection coefficient. Thaum twgdaim ntawv xeem yog LPS -101, nrog rau cov qauv hauv qab no qhov concentration ntawm tsawg ntomLipoprotein cholesterol nyob rau hauv (LDL) yog xam, qhov piv ntawm TC thiab HDL kuj yogxam.

LDL =TC-HDL-TG/5 (mg/dL)

LDL =TC-HDL-TG/2.2 (mmol/L)
